Renogy N-Type 16BB 100W Solar Panel, 12V 100 Watt Solar Panel 25% High-Efficiency, PV Module Power Charger for RV Marine Rooftop Farm Battery and Other Off-Grid Applications
todaydealshub.com
Price: $174.99 - $99.74
(as of Dec 05, 2024 09:41:16 UTC – Details)
Product Description
1 25% High-Efficiency
2 Provide More Output
3 Premium Quality
4 High Temp Advantage
16BB for Higher Conversion Efficiency
Advanced 16BB cell technology maximizes energy conversion while enhancing durability by minimizing the risk of microcracks.
Stronger Aluminum Frame for Enhanced Durability
Crafted from aluminum alloy over 1.1mm thick, this solar panel boasts a sturdier frame compared to competitors’, ensuring enhanced durability.
Compatible with 99% of Charge Controllers
This panel, with an open-circuit voltage of less than 25V, is compatible with various MPPT/PWM charge controllers.
Effortless Power, Compactly Installed
This 100W n-type solar panel is 8% lighter and 11% smaller than a p-type PERC 100W solar panel. This makes installation easier and allows for more space for panel expansion.
1 Class B Van
2 Class C RV
3 Marine
Specifications
Max Power at STC 100W Open Circuit Voltage 22.79V Short Circuit Current 5.31A Optimum Operating Voltage 19.97V Optimum Operating Current 5.01A Cell Efficiency 25% Dimensions 34.1×22.8×1.2in/865x578x30mm Weight 13.0lbs/5.9kg Maximum System Voltage 600VDC Maximum Series Fuse Rating 15A Module Efficiency 20.0% Operating Temperature -40°F~194°F / -40℃~90℃
What does off-grid and on-grid mean ?
On-grid simply means solar power equipment (array or solar panel) is connected to the electrical grid, while off-grid refers to systems that are not connected to the grid and therefore store the generated power for later use.
Why is my solar panel under producing ?
Solar panel performance may be hindered for a number of reasons. Most commonly environmental conditions such as indirect sunlight, temperature rise, cloudy sky, and dirt and stain build up on the top glass will cause a reduced power output.
How should I connect solar panels in my electrical circuit (series vs parallel)
Connecting solar panels in series will have the effect of adding up their operating voltage output, while system current output will be the same as that for one panel. While, connecting solar panels in parallel will have a different effect;
How many solar panels do I need ?
To determine solar panel needs, calculate the power load (Watts) and capacity (Watt-hours). Size the battery bank based on minimum capacity, then adjust panel quantity or power input accordingly.
What is the meaning of 12V in the product title，Why is this value different from the voltage of the solar panel？
When you open the product page, you will see a title like “xxx Watt 12 Volt Solar Panel”. The “12V” here does not refer to the voltage of this solar panel (VOC or VMP), but to the fact that one xxxW solar panel is suitable for 12V system.
Unmatched Cell Efficiency – Renogy’s 100W 12V N-Type Solar Panel features grade A+ cells, delivering an impressive conversion efficiency of 25%. This provides 20W more power output compared to conventional p-PERC panels of the same design.
16BB for Higher Conversion Efficiency and Longer Lifespan – Utilizing advanced 16BB cell technology, this n-type solar panel enhances photoelectric conversion efficiency while mitigating hot spots and hidden cracks, ensuring a longer service life and superior module performance.
Enhanced Performance in High Temperatures – Renogy’s 100W 12V N-Type Solar Panel features a low temperature coefficient of -0.29%/℃, minimizing power loss in high-temperature conditions for superior product performance. This allows for increased power generation, particularly beneficial in summer months or extremely hot areas.
Built to Last – Equipped with IP65 protection, the Renogy 100W N-Type Solar Panel is designed to endure snow, rain, and heat for decades. With low-iron tempered glass and corrosion-resistant aluminum frames, it ensures exceptional performance in all weather conditions.
10-Year Warranty – This n-type solar panel comes with a 10-year service plan for materials and workmanship, along with a 25-year commitment to maintain 80% output.
